| Defibrillator |
| Waveform | Biphasic Truncated Exponential with voltage and duration compensation for patient impedance |
| Patient impedance range | 10 – 300 ohms |
| Energy accuracy | - 10% of the energy setting into 50 ohms
- 15% of the rated energy output into 25 – 175 ohms
|
| Output energy sequence | Multiple levels, configurable from 150 joules to 360 joules |
| Energy default | - 200J, 300J, 360J (adult)
- 50J, 75J, 90J (pediatric)
|
| Shock Advisory System | An ECG analysis system that advises whether a shock is appropriate |
| cprINSIGHT™ analysis technology | Enables the defibrillator to analyze the patient's heart rhythm while CPR is being performed |
| CPR coaching | Instructions for adult and pediatric CPR, including feedback when no CPR is detected, rate and depth guidance, a metronome and instructions on hand placement |
| Time to shock at 360J after CPR (with cprINSIGHT enabled) | < 13 seconds |
| Charge time | 0 seconds for first 150J or 200J shock (as device is pre-charged). With cprINSIGHT enabled, subsequent shocks will be charged during CPR and ready to shock at the end of the CPR period |
| Controls |
| Lid release/ON-OFF | Controls device power |
| Shock button, fully automatic | Flashes prior to delivering shock without requiring user intervention |
| Child Mode button | Allows operator to switch to Child Mode for reduced energy and CPR guidance appropriate for children |
| Language button | Feature allows operator to switch between the primary and secondary languages (English-Spanish) |
| Electrical protection | Input protected against high voltage defibrillator pulses per IEC 60601-1/EN 60601-1 |
| Safety classification | Internally powered equipment. IEC 60601-1/EN 60601-1 |
| User interface |
| User interface | The user interface includes voice prompts and audible tones |
| ClearVoice™ technology | Detects background noise and adjusts audio and voice prompts to ensure they can be heard clearly in noisy environments |
| Device status indicators | Visual and audible indicators indicating system readiness (device, pads and battery). |
| Environmental |
| Note | All performance specifications defined assume the unit has been stored (two hours minimum) at operating temperature prior to operation |
| Operating temperature | - +32° to +122°F
- (0° to +50°C)
|
| Storage temperature | -22° to +140°F (-30° to +60°C) with battery and electrodes, maximum exposure time limited to one week |
| Long term storage | Always store the defibrillator within the recommended temperature range of 59° to 95°F (15° to 35°C) |
| Altitude | -1,253 to 15,000 ft (-382 to 4,572 m) |
| Relative humidity | 5 to 95% (non-condensing) |
| Dust and water resistance | IEC 60529/EN 60529 IP55 with electrodes connected and battery installed |
| Shock | IEC 60068-2-27, (40g, 11 ms pulse, ½ sine each axis) |
| Vibration | MIL-STD-810G, method 514.6, helicopter – category 14 and ground vehicle – category 20 |
| Data storage |
| Memory type | Internal digital memory (flash RAM) |
| ECG storage | Minimum 60 minutes of ECG stored for two patient episodes |
| Communications | - USB
- Wireless 802.11 b/g/n data transfer to LIFELINK central™ AED
- program manager or LIFENET® System
|
| Physical characteristics with handle, including electrodes and battery |
| Height | 3.8 in (9.7 cm) |
| Width | 8.9 in (22.6 cm) |
| Depth | 10.8 in (27.4 cm) |
| Weight | 4.5 lb (2.0 kg) |
